GSM 7670 4G
Rs. 1,357.00
Skip to product information
GSM 7670 4G
Rs. 1,357.00
Need a larger quantity? Get a bulk quote.
The GSM 7670 4G module is built around the SIMCom A7670C LTE chip and supports LTE-FDD, LTE-TDD, GSM, GPRS, and EDGE networks. Features an RS232 DB9 interface for PC connection, a 1.8V UART header for direct microcontroller interfacing, and onboard SIM card holder. Controlled via AT commands. Downlink up to 10Mbps, uplink up to 5Mbps.
Specifications:
- Module: SIMCom A7670C
- Networks: LTE-FDD, LTE-TDD, GSM/GPRS/EDGE
- DC Jack Input: 9–12V
- Downlink: up to 10Mbps
- Uplink: up to 5Mbps
- Interface: RS232 DB9, 1.8V UART header
- Antenna: SMA connector (external)
- Onboard: SIM card holder, power LED, network status LED
- Control: AT commands
Applications:
- IoT cellular data communication
- GSM/LTE enabled microcontroller projects
- Remote monitoring and telemetry
- SMS and data transfer over 4G networks
