LCD GRAPHIC 64X128
Rs. 649.00
Need a larger quantity? Get a bulk quote.
The JHD12864E is a 128×64 dot graphic LCD with KS0108 controller. Supports both 8-bit parallel and SPI serial interfaces. Yellow-green backlight with white pixels. Capable of displaying full graphics, text, animations, and menus. Widely used in 3D printers (RAMPS extension) and Arduino graphical display projects.
Specifications:
- Controller: KS0108
- Resolution: 128 × 64 dots
- Interface: 8-bit parallel or SPI (3-wire)
- Display: Yellow-green, positive transflective
- Driving: 1/64 duty, 1/9 bias
- Supply Voltage: 5V
- Operating Temperature: -20 to +70°C
- Type: COB (Chip on Board)
- Connector: Header pins
Applications:
- 3D printer display (RAMPS controller)
- Arduino graphical UI and menu systems
- Embedded instrument displays
- Data logging and visualisation
