LORA 02
Rs. 330.40
Skip to product information
LORA 02
Rs. 330.40
Need a larger quantity? Get a bulk quote.
The Ai-Thinker LoRa Ra-02 is a 433MHz SX1278-based RF transceiver module with LoRa spread spectrum modulation. Up to 15km range in open areas. +20dBm TX power, -148dBm receiver sensitivity. SPI interface, onboard patch antenna, shielded housing, castellated SMD package. For Arduino use with the LoRa library (install via Arduino IDE Library Manager). Supports LoRa, FSK, GFSK, MSK, GMSK, and OOK modulation.
Specifications:
- Model: Ra-02
- Chip: SX1278
- Frequency: 433MHz
- TX Power: +20dBm (100mW)
- RX Sensitivity: -148dBm
- RSSI Range: 127dB
- Communication Range: up to 15km (open area)
- Modulation: LoRa, FSK, GFSK, MSK, GMSK, OOK
- Interface: Half-duplex SPI
- Bit Rate: up to 300kbps
- Antenna: Onboard patch antenna
- Package: SMD castellated (dual-row stamp-hole)
Applications:
- Smart metering and AMR
- Home and building automation
- Long-range IoT sensor networks
- Wireless alarm and security systems
- Agriculture and irrigation remote monitoring
