MAX232 RS-232 / TTL Level Converter IC DIP-16 (Min 5 Pcs)

The MAX232 is the industry-standard RS-232 to TTL/CMOS level converter IC in DIP-16 package. Converts RS-232 serial signals (±12V) to 5V TTL logic levels and vice versa using only four external 1µF capacitors — the classic solution for connecting microcontrollers to PC serial ports and RS-232 devices. Sold in a minimum of 5 pieces.

Specifications

• Type: Dual RS-232 Driver/Receiver
• Supply Voltage (VCC): 5V single supply
• RS-232 Output Voltage: ±7.5V to ±13.5V (charge pump generated)
• Data Rate: Up to 120kbps
• Channels: 2 drivers + 2 receivers
• External Capacitors: 4 × 1µF (charge pump)
• Package: DIP-16

Applications

Microcontroller to PC RS-232 serial interface, Arduino UART to RS-232, TTL to DB9 serial port adapter, GSM modem interface, PLC communication, embedded UART debug port, industrial serial communication.
