POWER DISTRIBUTION BOARD
Rs. 236.00
Need a larger quantity? Get a bulk quote.
Compact 100A Power Distribution Board (PDB) for multi-rotor aircraft. Solder a battery lead to the two central terminals and get eight pairs of ESC output connections. Handles up to 20A per output on a quadcopter (10A each on an octocopter). Large solder pads for easy wiring. Compatible with MK/KK flight control systems with 45mm and 35mm mounting hole patterns.
Specifications:
- Maximum Total Current: 100A
- Output Connections: 8 pairs (supports 1–8 ESCs)
- Per-Output Current: Up to 20A (quad) / 10A (octo)
- Mounting Holes: 45mm square + 35mm square
- Compatible: MK/KK flight control systems
- Large solder pads for easy assembly
- Lightweight design
Applications:
- Quadcopter, hexacopter, and octocopter power distribution
- DIY drone frame builds
- Racing and FPV drone power wiring
