SG90

The TowerPro SG90 is a lightweight 180° micro servo motor with digital PWM control. Rotates 90° in each direction. Sturdy plastic housing provides water and dust resistance. 3-wire JR plug (Futaba compatible). Suitable for RC aircraft, boats, robots, and Arduino servo projects.

Wire Colours:

• Red — VCC (positive)
• Brown — GND
• Orange — Signal (PWM)

Specifications:

• Model: SG90
• Rotation: 180° (±90°)
• Operating Voltage: 4.8–6V
• Speed @ 4.8V: 0.10 sec/60°
• Stall Torque @ 4.8V: 1.2 kg·cm
• Stall Torque @ 6.6V: 1.6 kg·cm
• Gear Type: Glass fibre
• Connector: JR (Futaba compatible)
• Operating Temperature: −30 to +60°C

Applications:

• RC aircraft, boats, and vehicles
• Arduino and robotics servo control
• Pan/tilt camera gimbal mounts
• Lightweight actuator for maker projects
