TPA3110 Class D Audio Amplifier Module
Rs. 141.60
Skip to product information
TPA3110 Class D Audio Amplifier Module
Rs. 141.60
Need a larger quantity? Get a bulk quote.
The TPA3110 is a stereo Class D audio amplifier module based on the Texas Instruments TPA3110D2 IC. It delivers high efficiency audio amplification with minimal heat generation, making it ideal for portable speaker and audio projects.
Specifications
- IC: Texas Instruments TPA3110D2
- Operating Voltage: 4.5V – 18V DC
- Output Power: 2 × 15W (stereo) at 8Ω / 2 × 30W (mono bridged)
- Efficiency: Up to 87%
- THD+N: 0.1% (typ.)
- Frequency Response: 20 Hz – 20 kHz
- Interface: Analog audio input (3.5mm or screw terminal)
- Dimensions: 46 × 26 mm (approx.)
- Weight: ~10 g
Applications
DIY speakers, Arduino/Raspberry Pi audio projects, portable amplifiers, PA systems.
